heat transfer system

heat transfer system Specification

Usage & Applications
Industrial heating processes, chemical, pharmaceutical, and food industries

Type
Heat Transfer System

Material
Mild Steel

Capacity
500 Liters

Voltage
380 V

Power
10 kW

Power Source
Electric

Input Voltage
380 V

Output Voltage
220 V

Installation Type
Floor Mounted

Dimension (L*W*H)
1800 mm x 900 mm x 1450 mm

Weight (kg)
220 kg

Color
Light Grey

Surface Finish
Powder Coated

Heat Transfer Medium
Thermic Fluid

Control System
Digital Temperature Controller

Insulation Material
Mineral Wool

Heating Method
Indirect Electric Heating

Automation Grade
Semi-Automatic

Inlet/Outlet Connection Size
2 inches

Safety Feature
Overheat Protection

Frequency
50 Hz

Temperature Range
Up to 250C

heat transfer system Trade Information

Minimum Order Quantity
210 Liters

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Cash in Advance (CID), Cheque, Delivery Point (DP)

Supply Ability
1 Liter Per Week

Delivery Time
1 Hours

Sample Available
No

Sample Policy
Free samples are available

Packaging Details
drum

Main Export Market(s)
Asia

Main Domestic Market
All India

About heat transfer system

EUROTHERM-NXG

The Next-Generation's Thermic Fluid

Premium Performance | Cost-Effective | Long-Lasting

Welcome to Eurotherm-NXG, Indias next-generation Thermic Fluid Oil (Heat Transfer Fluid) by Precitech Thermal, designed for high-performance industrial heating applications. A collaboration between Precitech Thermal (25+ years of expertise) and ENI-Italy (global leader in specialty oils), Eurotherm-NXG offers world-class thermal stability, efficiency, and reliabilityat a cost-effective price.

High-Performance Industrial Heating

Our Heat Transfer System is engineered for a variety of industrial heating processes, including chemical, pharmaceutical, and food processing applications. The robust mild steel body, mineral wool insulation, and powder-coated finish ensure longevity and optimal performance, even under challenging conditions. Overheat protection and digital temperature controls guarantee safe, accurate, and consistent results every time.

Efficient and Cost-Effective Operation

Indirect electric heating combined with a thermic fluid medium provides uniform thermal distribution while optimizing energy use. The 10 kW system operates seamlessly with standard 380 V electric supply, making it both powerful and energy efficient. Its semi-automatic controls and digital interface streamline operation and monitoring, reducing personnel requirements and minimizing operational complexity.

Reliable and User-Friendly Design

The system features easy-to-use digital temperature controllers for fine tuning, 2-inch inlet and outlet connections for straightforward fluid handling, and sturdy floor-mounted installation. With a compact form factor and light grey powder coating, it integrates well with most industrial settings. A comprehensive safety framework, including overheat protection, enhances operational security during prolonged use.

FAQ's of heat transfer system:

Q: How does the heat transfer system achieve precise temperature control?

A: The system uses a digital temperature controller, allowing operators to accurately set and monitor the desired temperature up to 250C. Indirect electric heating with thermic fluid ensures stable and uniform heat distribution across industrial processes.

Q: What industries or processes is this heat transfer system best suited for?

A: This unit is ideal for industrial heating applications in the chemical, pharmaceutical, and food industries, where consistent process temperatures and enhanced safety are needed. Its reliability and versatility make it suitable for a wide range of manufacturing settings.

Q: When should I select a thermic fluid heat transfer system over other heating methods?

A: Choose a thermic fluid heat transfer system when your application requires indirect, uniform heating up to moderate-high temperatures, precise temperature control, and energy efficiency, especially in sensitive processes where direct heating is not desirable.

Q: Where can this system be installed and how much space is required?

A: Designed as a floor-mounted unit, the system has dimensions of 1800 mm x 900 mm x 1450 mm and weighs 220 kg. It fits comfortably in most industrial environments, requiring a stable surface with access to a 380 V power supply and suitable ventilation.

Q: What safety features are included with the heat transfer system?

A: The system incorporates robust overheat protection, preventing the unit from exceeding safe temperature limits. Mineral wool insulation ensures external surfaces remain cool, adding an extra layer of operational safety.

Q: How is the heating process managed and what are the power requirements?

A: The system operates semi-automatically, managed via digital controls. It requires a 10 kW power supply at 380 V input and delivers 220 V output, compatible with standard industrial electrical infrastructure.

Q: What are the key benefits of using this heat transfer system in industrial applications?

A: Key benefits include precise temperature regulation, uniform heat transfer, reduced operational risk due to safety features, energy efficiency thanks to indirect heating, straightforward installation, and low maintenance requirements.
